User Guide

So, you’ve installed Kovri. Now what?

Step 1. Open your NAT/Firewall

Choose a port between 9111 and 30777
Save this port to your configuration file (kovri.conf)
Poke a hole in your NAT/Firewall to allow incoming TCP/UDP connections to that port (See notes below if you don’t have access)

Notes:

If you don’t save the port, kovri will randomly generate a new one on each startup (you also have the choice to pass the port with the --port flag on each startup).
If you don’t have access to your NAT, use the --enable-upnp runtime option or enable the option in kovri.conf
Don’t share your port number with anyone as it will affect your anonymity!

Step 2. (Recommended) Operational security

Consider creating a designated kovri user and run kovri only using that user
If using Linux, consider using a hardened kernel (such as grsec with RBAC)
After installing the appropriate resources in your kovri data path, considering setting appropriate access control with setfacl, umask, or whatever your OS uses for ACL
Never share your port number with anyone as it will affect your anonymity!

Note: see kovri.conf to find your data path for Linux/OSX/Windows

Step 3. Configure Kovri, setup tunnels

For a full list of options:

$ ./kovri --help

For complete options with details:

kovri.conf configuration file for router and client
tunnels.conf configuration file for client/server tunnels

Step 4. (Optional) Setup tunnels

In short, client tunnels are tunnels which you use to connect to other services and server tunnels are used for when you host service(s) (and other people connect to your service).

By default, you will have client tunnels setup for IRC (Irc2P) and email (i2pmail). To add/remove client tunnels, see tunnels.conf.

When creating server tunnel(s), you’ll need to create persistent private keys. To do so, uncomment or create keys = your-keys.dat and replace your-keys with an appropriate name. Do not share your private .dat file with anyone, and be sure to make a backup!

Once setup, your Base32 address will be shown in your log after you start kovri. You can also find the address in a text file along with the private keys file in your kovri data path in the client/keys directory. The address inside this .txt text file is safe to distribute so other people can connect to your service.

Example:

Private keys file: client/keys/your-keys.dat
Public Base32/Base64 address: client/keys/your-keys.dat.txt

Note: see kovri.conf to find your data path for Linux/OSX/Windows

Step 5. (Optional) Register your new eepsite

Stop! Until #498 is resolved, consider only registering your service with Kovri and not stats.i2p!

Open a request with [Subscription Request] your-host.i2p (replace your-host.i2p with your desired hostname) on the Kovri issue tracker
In the request body, paste the contents of your public .txt file that was mentioned in the previous step
After review, we will add your host and sign the subscription
Done!

Step 6. Run Kovri

$ cd build/ && ./kovri

Wait 5 minutes or so to get bootstrapped into the network before attempting to use services

Step 7. Join us on IRC

Startup your IRC client
Setup your client to connect to kovri’s IRC port (default 6669). This will connect you to the Irc2P network (I2P’s IRC network)
Join #kovri and #kovri-dev

Step 8. Browse an I2P website (garlic-site/eepsite)

Startup a browser of your choosing (preferably a browser devoted to kovri usage)
Configure your browser by reading these instructions but instead of port 4444 and 4445 change HTTP proxy port to 4446 and SSL proxy port also to 4446
Visit http://check.kovri.i2p

Notes:

Just like with Tor, one doesn’t need SSL to safely and securely use the network
SSL site support and outproxy service is not currently implemented
If someone gives you a .i2p address that’s not in your address book, use the Jump service at http://stats.i2p/i2p/lookup.html
Look through hosts.txt in your data directory to view a list of default sites you can easily visit
Overall, HTTP Proxy and address book implementation are in development and not yet feature-complete

Step 9. Enjoy!

Read more about Kovri in the Moneropedia.
Open your feature requests or report bugs on our issues tracker
Learn more about the I2P network on the java I2P website

Container Options

Snapcraft

On Linux systems, use snapcraft for easy deployment.

Step 1. Get the Kovri source repo

$ git clone --recursive https://github.com/monero-project/kovri

Step 2. Install snapcraft

Refer to your distribution’s package manager for snapcraft and snapd

On Ubuntu, simple run:

$ sudo apt-get install snapcraft

Step 3. Create the snap

$ cd kovri/ && snapcraft && sudo snap install *.snap --dangerous

Note: the –dangerous flag is needed only because the snap has not been signed (you built it yourself though, so this shouldn’t be an issue)

Step 4. Run Kovri with snapcraft

$ snap run kovri

Docker

Step 1. Install Docker

Installing Docker is outside the scope of this document, please see the docker documentation

Step 2. Configuring / Open Firewall

The docker image comes with the defaults of kovri, but can be configured as explained in earlier sections.

You should choose a random port and open that port (see earlier sections).

Step 3. Running

Default Settings

KOVRI_PORT=42085 && sudo docker run -p 127.0.0.1:4446:4446 -p 127.0.0.1:6669:6669 -p $KOVRI_PORT --env KOVRI_PORT=$KOVRI_PORT geti2p/kovri

Custom Settings

Where ./kovri-settings/ contains kovri.conf and tunnels.conf.

KOVRI_PORT=42085 && sudo docker run -p 127.0.0.1:4446:4446 -p 127.0.0.1:6669:6669 -p $KOVRI_PORT --env KOVRI_PORT=$KOVRI_PORT -v kovri-settings:/home/kovri/.kovri/config:ro geti2p/kovri
